Bosch MD1CS004 ECU Solutions

Map detection, patch generation and the tuning operations Map Decoder actually supports on the Bosch MD1CS004 engine control unit.

Bosch MD1CS004 at a glance

Bosch MD1CS004 ECU — supported tuning functions: AdBlue / SCR Off, Catalyst Off, DPF Off, EGR Off, Lambda / O2 — 1,153 mapped DTC codes
Bosch MD1CS004 — supported functions, vehicle brands and example vehicle.

ECU overview

ECU manufacturer
Bosch
ECU family
MD1
ECU model
MD1CS004
Supported solutions
10
Mapped DTC codes
1,153
Vehicle brands
Audi, Porsche, Seat, Skoda, VW

The Bosch MD1CS004 is part of the MD1 generation from Bosch. In the Map Decoder database it is linked to Audi, Skoda, VW, Seat and Porsche vehicles. Coverage for this ECU is built from 90 stored modifications learned on real original and modified files.

Supported solutions

What Map Decoder can do on an MD1CS004 file

Every operation below is backed by a stored, verified modification for MD1CS004. Nothing is listed that the software cannot actually perform on this ECU.

AdBlue / SCR Off

Turns off the SCR / AdBlue dosing strategy and its countdown logic in MD1CS004.

Catalyst Off

Disables catalyst efficiency monitoring in MD1CS004.

DPF Off

Removes diesel particulate filter regeneration and monitoring logic from MD1CS004 files.

EGR Off

Disables exhaust gas recirculation control in MD1CS004 calibrations, including the related fault reporting.

Lambda / O2

Disables lambda / O2 sensor monitoring in MD1CS004 without breaking fuelling.

MAF Off

Removes mass air flow sensor dependency and its diagnostics from MD1CS004.

NOx Off

Disables NOx sensor monitoring and the associated fault paths in MD1CS004.

Speed Limiter (VMAX) Off

Removes the top speed limiter from MD1CS004.

Stage 1

Software-only performance calibration for MD1CS004, with the supporting limiter changes.

Throttle Valve (TVA)

Disables throttle valve actuator control and monitoring in MD1CS004.

How it works

Map detection and patch generation for MD1CS004

Map detection

Upload an original MD1CS004 read. Map Decoder locates the relevant calibration tables automatically instead of relying on a fixed address list, so files from different software versions are handled.

Patch generation

A stored modification is only offered when it fits your binary. Region similarity and anchor signatures are checked against the uploaded file first, so a change learned on one software version is never blindly written to another.

Checksum correction

Checksums covering the regions a patch touches are recalculated as part of patch generation, so the ECU accepts the modified flash.

DTC

MD1CS004 DTC codes

Map Decoder holds 1,153 diagnostic trouble codes for the MD1CS004. Each entry stores the address and the byte values measured on a real file.

  • B0086
  • B0087
  • B0167
  • B0168
  • B023E
  • B0429
  • B0498
  • B049A
  • B0650
  • B0651
  • B06F7
  • B07AF
  • B0A23
  • B0A2B
  • B0A39
  • B0A3D
  • B0A3E
  • B0A95
  • B1090
  • B1094
  • B1095
  • B1096
  • B1097
  • B1098

All 1,153 MD1CS004 DTC codes

Related ECUs

Other MD1 ECUs

Vehicles

Vehicle brands using the MD1CS004

Brand + solution

MD1CS004 solutions by vehicle brand

Related families

Other Bosch ECU families

FAQ

Bosch MD1CS004 — frequently asked questions

What is the Bosch MD1CS004?

The MD1CS004 is an engine control unit produced by Bosch, part of the MD1 generation. It is used in Audi, Porsche, Seat, Skoda and VW vehicles.

Can Map Decoder identify maps in MD1CS004 files?

Yes. Upload an original read and the relevant calibration tables are located automatically. The result is verified against the binary before any patch is offered, so a mismatched file is rejected rather than silently patched.

Which operations are supported for the Bosch MD1CS004?

Validated operations for this ECU: AdBlue / SCR Off, Catalyst Off, DPF Off, EGR Off, Lambda / O2, MAF Off, NOx Off, Speed Limiter (VMAX) Off, Stage 1 and Throttle Valve (TVA). They come from 90 stored modifications learned on real files.

Does Map Decoder support DTC removal on the MD1CS004?

Yes. 1,153 diagnostic trouble codes are mapped for this ECU, each with the address and the byte values measured on a real file rather than a guessed constant.

Does Map Decoder correct the checksum after patching an MD1CS004 file?

Yes. Checksums covering the regions a patch changes are recalculated during patch generation, so the modified file is accepted by the ECU.

Work on Bosch MD1CS004 files

Map Decoder analyses Bosch MD1CS004 files, detects the maps and generates a verified patch with the checksum corrected.
